Consecutive operating temperature 180°C

Flammability: UL94 V-0

PEEK has excellent chemical properties.  PEEK exhibits very good friction-proof and abrasion-proof properties.

  1. Production methodology differs from metal screw production, so some variation is normal.  All products are in accordance with JIS and ISO standards.

  2. Chemical resistance may vary with temperature.  Be sure to evaluate under conditions of actual expected use.

  3. For more details on material properties, click here.

  4. Specifications subject to change without notice.

  5. Custom orders available upon request.

  6. VICTREX is a registered trademark of Victrex, Inc.

  7. Click here for more information on PEEK from Victrex

  8. Click here for Victrex ROHS certification


  1. Please tighten to measured torque values.

  2. For the best results in compression applications, it is strongly recommended that PEEK screws be used in conjunction with PEEK nuts.

  3. When PEEK screws are used in threaded holes without nuts, the contact surface should be less than 20mm.
